Remote Control
MSG Matrix Switchers • Remote Control
5-6
Mute all outputs
[MUTE]
Toggle between mute and unmute for all outputs.
Mute status
[MUTE?]
Returns mute status for all outputs
Change output volume level - specific
[VOLoox]
Changes the volume level for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x
= + (plus sign) to increment the output volume.
x
= - (minus sign) to decrement the output volume.
x
= @ to return the output volume to factory default.
x
= ? to request the current volume level.
Set output volume level - specific
[VOLooxxx]
Sets the volume level for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
xxx
= -550 - 090
Note
: 090 equals maximum gain (+9dB), 000 equals factory
default (unity gain), and -550 equals minimum gain (-55dB).
Volume level - left
[VOLL?]
Returns all left audio output levels.
Change channel volume level - left
[VOLLoox]
Changes the left channel volume level for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x
= + (plus sign) to increment the output volume.
x
= - (minus sign) to decrement the output volume.
x
= @ to return the output volume to factory default.
x
= ? to request the current volume level.
Set channel volume level - left
[VOLLooxxx]
Sets the left channel volume level for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
xxx
= -550 - 090
Note
: 090 equals maximum gain (+9dB), 000 equals factory
default (unity gain), and -550 equals minimum gain (-55dB).
Change channel volume level - right
[VOLRoox]
Changes the right channel volume level for a specific output.
• Where:
oo
= 01 - 04 (MSG0804) or 01 - 08 (MSG0808) for output.
x
= + (plus sign) to increment the output volume.
x
= - (minus sign) to decrement the output volume.
x
= @ to return the output volume to factory default.
x
= ? to request the current volume level.
Volume level - right
[VOLR?]
Returns all right audio output levels.
