6

IPCP 505 • Setup Guide (Continued)

Extron Headquarters

+1.800.633.9876 (Inside USA/Canada Only)

Extron USA - West

Extron USA - East

+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX

+1.919.850.1001 FAX

Extron Europe

+800.3987.6673
(Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX

Extron Asia

+65.6383.4400
+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655
+81.3.3511.7656 FAX

Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX

Extron Middle East

+971.4.299.1800
+971.4.299.1880 FAX

Extron Korea

+82.2.3444.1571
+82.2.3444.1575 FAX

Extron India

1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX

© 2013 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners.

www.extron.com

If you have questions during installation and setup, you can call the

Extron S3 Sales & Technical Support Hotline or the

Extron S3 Control Systems Support Hotline

.

68-2026-51

Rev. B

07 13

Mounting

Securely mount the IPCP and other devices and attach cables using the preceding wiring section as a guide.
Optional 1U rack shelves (such as the RSU 129 1U 9.5" Deep Universal Rack Shelf and the RSB 129 1U 9.5" Deep Basic Rack
Shelf) are available for use with the IPCP. Read the instructions and UL guidelines that come with the rack shelf or mounting kit for
installation procedures.

Setup Checklist: How to Proceed With Installation

Get Ready

…

Familiarize yourself with the features of the IPCP 505.

…

Download and install the latest version of the Extron Global Configurator (GC) software and the latest driver
package (avail able from

www.extron.com

or on the Extron Software Products Disc.)

…

Obtain IP setting information for the IPCP from the network administrator.

…

Obtain model names and setup information for devices the IPCP will control.

Perform Physical Installation

…

Mount the unit to a rack.

…

Cable devices to ports on the IPCP 505.

…

Connect power cords and turn on the devices in the following order: output devices (projectors, monitors,
speakers), the IPCP, a PC (for setup) or touchpanel (for control after configuration), then all input devices (such
as DSS and cable boxes).

Configure the IPCP

…

Connect the PC and the IPCP 505 to the same Ethernet subnetwork and use ARP via Telnet, Extron DataViewer,
or a similar application to configure the IPCP for network communication.

…

Connect any Extron TLP touchpanels that will be part of the system to the same network as the PC and IPCP.
Create a user interface layout for the touchpanels and upload the GUI configuration to each touchpanel. See the
GUI Configurator Help file for instructions.

…

Create a new GC project and configure the IPCP 505. See the Global Configurator Help file.

…

Test the system.

Contact information
