Page 7
7
Control, Unidirectional — IR/Serial
IR/SERIAL
5
6
7
8
2
1
3
4
IR/S
1
2
IR/SERIAL
1
S G
2
S G
IR/SERIAL
S G S G
S G S G
S G S G
S G S G
1
2
5
6
3
4
7
8
Rear Panels
Front Panels
S
G
(-)
(+)
(-)
(+)
(+)
(-)
To the IR Receiver of a
Projector, Display, or
Source Device
Two Single IR Emitters
Ground
IR Output Signal
Unidirectional
IR
or
IR or RS-232
Output
Ground
To a Projector,
Panel Display, or the
Wired IR Remote or
RS-232 Port of a
Source Device
IR/Serial LEDs
Light when signals are transmitted
on the corresponding IR/serial port.
IR/Serial Ports
Output options:
• IR (30 kHz to 300 kHz,
with or without carrier signals)
• Unidirectional RS-232
or
or
Control, Unidirectional — Relays
RELAYS
2
1
4
3
C
C
RELAYS
1
2
5
6
3
4
7
8
RELAYS
5
6
7
8
2
1
3
4
Rear Panels
Front Panel
1
2
To Room
Control
Equipment
To Room
Control
Equipment
Closed
Normally
Open
Normally Open (2)
Common
Normally Open (1)
Common
Relays
• Connect devices for relay control.
• Do not exceed a total of 24 V at 1 A for each port.
Relay LEDs
Light when the corresponding
relays are activated (tied to GND).
or
Common
Relay 2
Relay 1
All relays
are
normally
open.
