Installation and
Operation
This section describes the installation and the operation of the HDMI 201, including:
• Mounting the Transmitter or Receiver
• Connections
• Operation
• Technical Points for Digital Video and Content Protection Encryption
• Troubleshooting
• Application Examples
Mounting the Transmitter or Receiver
CAUTION: Installation and service must be performed by authorized personnel only.
Non-Decora Unit Mounting
The 1-inch high, quarter rack width HDMI 201 (non-Decora) transmitters and receivers can
be placed on a tabletop, mounted on a rack shelf, or mounted under a desk or tabletop.
The receiver can be mounted on a projector bracket.
Tabletop use
Affix the four included rubber feet to the bottom of the unit and place it in any convenient
location.
Rack shelf mounting
For rack mounting, mount the transmitter or receiver using any of the following rack
mounting options:
• RSF 123 3.5-inch deep rack shelf kit (part #60-190-20) ( figure 2 )
• RSB 123 3.5-inch deep rack shelf (part #60-604-21)
• RSU 126 6-inch deep universal rack shelf kit (part #60-190-10)
• RSB 126 6-inch deep basic rack shelf (part #60-604-11)
• RSU 129 9.5-inch deep universal rack shelf kit (part #60-190-01) ( figure 3 )
• RSB 129 9.5-inch deep basic rack shelf (part #60-604-02)
HDMI 201 • Installation and Operation 5
