Figure 14, Figure 15. rca connector wiring – Extron Electronics HDMI 201 User Manual
Page 21
HDMI 201 Tx Rear Panel
POWER
12V
0.4A MAX
RS-232
PASS THRU
Tx Rx
1
2
HDMI INPUT
HDMI 201 Tx
PO
WER
12V
0.4A MAX
DO NOT
CONNECT
TO LAN
1
2
O
U
T
P
U
T
S
HDMI 201 A D Tx
L
A
UDIO
OUTPUT
R
4
6
HDMI 201 A D Tx Rear Panel
5
4
1
2
5
Figure 14.
HDMI 201 Tx Rear Panel Connectors
c
Input Audio (HDMI 201 A D Tx [Decora] only) connectors — Plug an
unbalanced stereo audio input into this pair, left and right, of female RCA connectors
(figure 15).
Sleeve (Gnd )
Tip (+)
Sleeve ( )
Right Channel
(Red Jacket)
Left Channel
(White Jacket)
Tip (Signal)
Figure 15.
RCA Connector Wiring
d
DC power input connector — Plug the included external 12 VDC power supply
into either this 2-pole connector or the power input connector on the receiver
(
HDMI 201 • Installation and Operation
17
