7.
Align the two slotted holes in the bottom of the L-shaped bracket with the two
slotted holes in the base of the tray. Secure the L-shaped bracket to the base by
inserting two provided 6-32 x 5/16-inch screws through the aligned slots.
8.
Move the PMK 350 up to the desired location on the ceiling pole, as close to the
ceiling as desired.
9.
Secure the L-shaped bracket to the U-bolt using the included hex nuts, washers, and
lock washers. Tighten the hex nuts securely.
NOTE: Be sure to tighten the hex nuts securely enough that the PMK 350 does not
slide down the ceiling pole. A socket wrench is recommended to tighten
the hex nuts.
10.
Secure the front and rear plates to the mounting tray with four of the included #6
screws.
11.
If desired, choose one of the provided four sizes of self-adhesive cover sheets, and
apply it to the underside of the mounting tray.
HDMI 201 • Installation and Operation
12
