Page 26: Command and response table
DTP T HWP/UWP 232/332 D Transmitters • Remote Control
20
Command and Response Table for SIS Commands
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Select and view input
Select an input
X!
!
In
X!
•All
]
Select input
X!
to transmit to the
connected receiver.
Example:
1!
In01•All
]
Select input 1.
View input selection
!
X!]
Input
X!
is selected.
Signal status
Request all signal status
E
OLS
}
Sig
X@
•
X@
*
X@]
0 = not detected
1 = detected
(Example: Input 1
•
Input 2
*
Output
HDCP status
View the HDCP status of a specific
input
E
I
X!
HDCP
}
HdcpI
X%]
X!
= input 1-2;
X%
= HDCP status
(HDMI inputs only)
View the HDCP status of both HDMI
inputs
E
IHDCP
}
HdcpI
X%
•
X%]
View the output HDCP status
E
OHDCP
}
X^]
Auto switch status
View the auto switch status
E
AUSW
}
X#]
0 = disabled (default)
1 = enabled (highest active input priority)
HDCP Authorized device
Set HDCP authorization per input
E
E
X!
*
X@
HDCP
}
HdcpE
X!
*
X@]
X!
= input (1 or 2)
X@
= 0 (disabled) or 1 (enabled, default)
Set HDCP authorization to all inputs
E
E
X@
HDCP
}
HdcpE
X@]
HDMI inputs only
View input HDCP authorization status
E
EHDCP
}
X@
•
X@]
Input video format (VGA input only, UWP models only)
Set input video format
2*
X1)
\
Typ2*
X1)]
X1)
= 0 (HDMI, default) or 1 = force
VGA inputs to DVI output
View current format
2\
X1)]
View current format of input 2.
View auto-detected format
2*\
X1)]
View auto-detected format of input
(
X1)
=1).
Force VGA DVI out (UWP models only)
Force VGA to DVI output
EX1(
VTPO
}
Vtpo
X1(]
X1(:
= 0 (HDMI, default) or 1 (force VGA
inputs to be DVI output)
View VGA to DVI output
E
VTPO
}
X1(]
View VGA DVI out status.
