DTP T HWP/UWP 232/332 D Transmitters • Installation and Operation 4
Installation and
Operation
This section describes the installation and the operation of the extenders, including:
• Mounting the Transmitter
• DTP T HWP 232 and 332 D Connections
• DTP T UWP 232 and 332 D Connections
• TP Cable Termination and Recommendations
• Power Supply Wiring
• RS-232 and IR Connector Wiring
• Operation
Mounting the Transmitter
ATTENTION:
• Installation and service must be performed by authorized personnel.
• The installation must conform to national and local building, electrical, and safety
codes and to the size requirements of the wall plate.
The transmitters can be installed in a two-gang electrical wall box, or with a mud ring, with a
Decora wall plate cover (supplied).
UL and Safety Guidelines
The following UL guidelines pertain to the installation of the Decora transmitters into a wall
or furniture.
• These units are not to be connected to a centralized DC power source or used beyond
their rated voltage range.
• These units must be installed in UL Listed wall boxes.
• These units must be installed with conduit in accordance with National Electrical Code.
