Command and response table for SIS commands (continued)
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
On-screen display timeout
Set menu timeout
EX1&
MDUR
}
Mdur
X1&]
Set the duration of the on-screen display.
View menu timeout
E
MDUR
}
Mdur
X1&]
View the duration of the on-screen display.
Switch and signal status requests
Request Audio switch status
E
STAT
}
EmbedAud
X1*]
Show the position of the Audio switch:
0 = off (embedded audio is muted) or 1 = on (unmute).
NOTE: The audio on the captive screw audio output always remains active regardless of the setting of this switch.
Check audio embed
E
5STAT
}
X1(]
Show if audio is embedded in the video stream:
0 = not detected or 1 = detected.
View link 1 (Tx-to-Rx) status
1S
X1(]
View link 2 (Rx-to-Tx) status
2S
X1(]
View input video status
3S
X1@]
View input audio status
4S
X1@]
View all signal status
5S
SigI
X1(
•
SigO
X1(
•
HdcpI
X1(
•
HdcpO
X1(]
Report the status of the HDMI input, HDMI output,
HDCP encoding on the input, and HDCP encoding on
the output.
View HDMI signal status
6S
SigI
X1(
•
SigO
X1(]
Report the status of the HDMI input and HDMI output.
View HDCP status
7S
HdcpI
X1(
•
HdcpO
X1(]
Report the status of the HDCP encoding on the input
and HDCP encoding on the output.
View temperature
20S
X2)
F
•
X2)
C
]
Show temperature in degrees Fahrenheit and Celsius.
View SFP module status
40S
X2!
•
X2@
•
X2#
•
X2$]
Example:
40S
JDSC
•
4.156mw
•
0.30mw
•
32C
Information requests
Information request
I
1Lnk
X1(
•2Lnk
X1(
•Vid
X1@
•Aud
X1@
•
X2%
•SR
]
The unit responds with the current status (signal
detected) of optical link 1, optical link 2, the video
input, and the audio link; and the fiber optic
transmission mode (singlemode or multimode).
Show firmware version
Q
X2^]
Example:
Q
1.23
]
The factory-installed firmware version is 1.23 (sample
value only).
Request part number
N
60-1187-nn
]
See “
Part Numbers
” on page 36.
Resets
Reset image settings
E
ZI
}
Zpi
]
Reset (clear) all image adjustments.
System reset
E
ZXXX
}
Zpx
]
Reset all settings to factory defaults.
NOTE:
X1@
= On and off status
0 = off
1 = on
X1&
= On-screen display timeout
0 = No display timeout
01 to 64 (seconds)
X1*
= Switch position
0 = off (down)
1 = on (up)
X1(
= Link status
0 = light or signal input not detected
1 = light or signal detected
X2)
= Internal temperature
nnnF•nnC
X2!
= Vendor/manufacturer name
X2@
= Transmit output power in milliwatts
X2#
= Receive optical power in milliwatts
X2$
= SFP temperature
nnC
X2%
= Transmission mode
SM = singlemode
MM = multimode
X2^
= Firmware version
v.vv
