Dante Controller User Guide
Copyright © 2013 Audinate Pty Ltd. All rights reserved.
-24-
Network View Menu bar
The menu bar in the Network View contains three menus: File, Device and Help.
File
n
Load Preset (Ctrl+L): loads a configuration from a file
n
Save Preset (Ctrl+S): saves configuration for currently displayed devices to a file
n
Exit (Alt+F4): Exits Dante Controller
The use of Presets is described in detail later in this guide.
Device
n
Refresh (F5): Refreshes the displayed network / device data
n
Device View (Ctrl+D): Opens a new Device View window
Help
n
About: Shows Dante Controller version and current log file
n
License: Displays the license text
n
Contents (Shift+F1): Opens a help window and displays help contents
Network View Toolbar
Below the menu bar there is a toolbar containing five buttons:
Reload Device Information
Updates the current view with the latest device information from
the network. This is useful when a recent change to the network
has not yet propagated automatically through to Dante Controller
(for example, a new device has been added to the network).
Load Preset
Loads a previously saved audio routing configuration. See
for more information.
Save Preset
Saves the current audio routing configuration. See
for more
information.
Choose a Dante Interface
Opens the Configure Dante Interfaces dialog. See
for more information.
Clock Health Monitoring
Activates the Clock Health Monitoring function. See
for more information.
To the right of the toolbar, Dante Controller displays the current
(or clocks, in the case of
redundant networks) and an indication of the current Dante multicast audio bandwidth on the network. Note
that there may also be traffic from other sources on the network.
Network View Tabs
There are four sub-views within the Network View that can be selected by clicking on the tabs below the
menu bar and toolbar. These are as follows:
n
Routing
n
Device status
