Cable Cubby 300/600/800 • Maintenance and Modifications 12
Maintenance and
Modifications
This section covers the following topics:
• Removing and Replacing the Cable Cubby
• Replacing Cables or an AAP
• Adding an Additional Power Module (CC 600, CC 800)
The Cable Cubby can be modified after installation to change cables, to replace an AAP, or
to add a second power module. These modifications may require removing the cubby from
the table.
Removing and Replacing the Cable Cubby
You may need to remove the cubby from the table in which it is mounted to replace cables
or AAPs, to adjust the height of the AAP assemblies, or to install a second power module.
Figure 11 on the next page shows removal of the Cable Cubby 300, 600, or 800 from the
table and removal of the AAP shelf assembly and power module.
Remove and replace the Cable Cubby for maintenance as follows:
CAUTION: Risk of electrical shock. Ensure that AC power is disconnected before
servicing the Cable Cubby.
1. Loosen the locking thumbscrews on the screw clamps to unlock the
clamp (see
figure 11 ).
2. Loosen the screw clamps.
3. Remove the screw clamps on both sides of the enclosure.
