A-3 Digital Display Scaler • Reference Information
Control/remote — video scaler/scan converter
Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin configurations 2 = TX, 3 = RX, 5 = GND
Program control .......................... Extron’s control/configuration program for Windows
®
Extron’s Simple Instruction Set (SIS ™ )
General
Power ............................................ 100 VAC to 240 VAC, 50/60 Hz, 30 watts, internal, autoswitchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, noncondensing
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, noncondensing
Rack mount .................................. Yes
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 17.5" W x 12" D (1U high, full rack wide)
4.4 cm H x 44.4 cm W x 30.5 cm D
Product weight ............................. 6.3 lbs (2.9 kg)
Shipping weight ........................... 11 lbs (5 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
Part Numbers
Included parts
These items are included in each order for a DDS 402:
Included parts Part number
DDS 402 60-426-01
Rubber feet (self-adhesive) (4)
Rack and through-desk mounting kit 70-077-03
IEC power cord
Tweeker (small screwdriver)
DDS 402 User’s Manual
USP 405/DDS 402 Windows-based control program
Suggested part
The following replacement part is available:
Included parts Part number
Button and cap diffuser kit 70-352-01
