You cannot use the numbers designating the number for a
in this column, you must use a 'real' ID-tag.
Column G
This column contains the signal type supplying data to this object.. These data
types exists:
Value
Description
D
Data for this object has comes from a digital input on a
A
Data for this object has comes from an analog input on
C
Data for this object has comes from a counter on a
M
Data for this object has comes from Modbus input on a
I
Data for this object has comes from an internal
Column H
This column contains the signal number supplying data to this object.. These data
types exists:
Value
Description
1
Data for this object has comes X-input number 1 on a
2
Data for this object has comes X-input number 2 on a
3
Data for this object has comes X-input number 3 on a
4
Data for this object has comes X-input number 4 on a
Column I
This column contains the number for the
supplying data to this
object. If the object just need to receive the 'standard' measurement the field must
contain a digit 0
Column J
This column contains information on any calculations which must be made before
data is delivered to an object in the SCADA-system. Calculations are done after
the SCADA plug-in has received the data but before it starts writing data to its file
with comma-separated values
If the field is empty - first character in the field is not a # - no
calculations are performed
