YSI IQ S ENSOR N ET TriOxmatic 702 IQ - Manual (Page 45)

TriOxmatic
®
702 IQ Technical data
7 - 3 ba76048e01 01/2012
7.3 General data
Dimensions
Weight (without sensor
connection cable)
approx. 660 g
Connection technique Connection via SACIQ sensor connection cable
Material
Automatic sensor
monitoring
(SensCheck function)
 SensReg (electrolyte solution depleted)
Instrument safety
7.4 Electrical data
40.0
358
30.0
Socket SACIQ...
Shaft V4A stainless steel 1.4571
Membrane head POM
Membrane FEP (thickness 25
μ
m)
Sensor head POM
Insulator PEEK
Plug head connector housing POM
Plug, 3-pole ETFE (blue) Tefzel
®
Applicable norms – EN 61010-1
– UL 3111-1
– CAN/CSA C22.2 No. 1010.1
Nominal voltage Max. 24VDC
via the IQ S
ENSOR N ET (for more
details, see chapter T ECHNICAL
DATA of the IQ S ENSOR N ET
system operating manual)
Power consumption 0.2 W
Protective class III
