Single-cell Li-Ion Charger IC with System Power Management AUR9807
Nov. 2011 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
6
Absolute Maximum Ratings (Note 1)
Parameter Symbol Value Unit
Supply Input Voltage V
IN
-0.3 to 18 V
V
BAT
, V
CE
, V
APM
, V
/PG
,
V
MODE
, V
OUT
, V
ISET1
,
V
ISET2
, V
STAT1
, V
STAT2
,
V
TS
-0.3 to 7 V
V
REF
-0.3 to V
OUT
+0.3 V
Input Voltage
V
TMR
-0.3 to V
OUT
+0.3 V
Input Current I
IN
3.5 A
I
OUT
4 A
Output Current
I
BAT
-4 to 1.5 A
Output Source Current
(In Regulation at 3.3V V
REF
)
I
REF
30 mA
Output Sink Current I
/PG
, I
STAT1
, I
STAT2
15 mA
Thermal Resistance
(Junction to Ambient)
θ
JA
52 °C/W
Storage Temperature T
STG
-65 to 150 °C
Junction Temperature T
J
-40 to 150 °C
Lead Temperature
(Soldering, 10 Seconds)
300 °C
ESD (Human Body Model) V
HBM
2000 V
ESD (Machine Model) V
MM
200 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under “Recommended Operating Conditions” is not implied. Exposure to “Absolute
Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Parameter Symbol Min Max Unit
AUR9807DSGD, AUR9807VSGD 4.35 6.3 V
Supply Voltage AUR9807DFGD,AUR9807VFGD,
AUR9807DIGD, AUR9807VIGD
V
IN
4.35 5.5 V
Input Current I
IN
2 A
Operating Junction Temperature Range T
OP
-40 125 °C
