LIST OF TABLES
TABLE TITLE PAGE
2-1 Bit System Description 12
2-2 System Data 12
2-3 Mechanical Data 13
2-4 Optical Data 13
2-5 Electrical Data 13
2-6 Environmental Data 14
2-7 IR850W Illuminator Data 14
2-8 Bit Standard Components 15
2-9 Optional Equipment 16
3-1 Controls and Indicators 23
3-2 IR Illuminator Controls 24
4-1 Preventive Maintenance Checks and Services 27
4-2 Operator Troubleshooting 29
A-1 Bit Spare Parts List 32
HOW TO USE THIS MANUAL
USAGE
You must familiarize yourself with the entire manual before operating the equipment. Read the entire
maintenance checklist before performing maintenance. Follow all WARNINGS, CAUTIONS, and NOTES.
MANUAL OVERVIEW
The Manual contains sections on operating and maintaining the Bit Digital Night Vision Monocular.
Throughout this Manual, the Bit Digital Night Vision Monocular will be referred to as the Bit or the
equipment.
A List of Spare Parts is in Appendix A.
The Product Warranty Registration Card is in Appendix B.
