TABLE 2-8. BIT STANDARD COMPONENTS
ITEM NO. DESCRIPTION qUANTITY
1 Armasight Bit Digital Night Vision Monocular
A Digital Night Vision device. 1
2 Objective Lens Cap
Protects the objective lens from dirt and mechanical damage, and provides protection
from light overload. Comes attached to the objective lens. 1
3 Eye-cup
A rubber cup used to protect the eyepiece as well as provide comfort for the operator.
Comes attached to the eyepiece. 1
4 Battery Cassette
Intended for the installation of two CR123 batteries in the battery compartment. The Bit
comes with two battery cassettes (includes one installed in the battery compartment
and one spare cassette). 2
5 CR123A Lithium Battery
Batteries are used to power the Bit. 2
6 Advanced Wireless Remote Control (AWREC)
Allows the user to operate the Bit in remote activation mode. Ensures quick and silent
activation/deactivation of the equipment. Comes with CR2032 (3V) battery installed. 1
7 Picatinny Adapter for Advanced Wireless Remote Control
Allows the advanced wireless remote control to be installed on a weapon’s Picatinny/
Weaver rail. 1
8 IR850W Detachable Wide Angle Adjustable X-Long Range Infrared Illuminator
A detachable LED long-range infrared illuminator with a wide, adjustable beam angle.
Compatible with night vision devices that rely on CCD or image intensifier technology.
Should be used when there is little to no ambient light. Comes fully assembled with a
dedicated mount in order to be installed on a Picatinny/Weaver rail. 1
9 Platform Ring
A dedicated mount with a Picatinny/Weaver rail, used to install on the top of the Bit and
additional equipment, such as the Armasight MCS Miniature Collimating Sight. 1
10 Video Cable
A cable used to connect the analog video input/output of the Bit to external display
devices (a monitor, TV) or power sources. The cable plug A is used for video, the plug B
is used for external power surse connection.
1
11 Afocal Doubler (Bit 5X-10X only)
2x magnifying lens intended for long-range operation. Comes complete with an thread
adapter and three M2×3 screws that are required to mount the lens to the Bit.
1
12 Operation and Maintenance Manual
Provides safety information, equipment description, mounting procedures, operating
instructions, and preventive maintenance checks and services (including a List of Spare
Parts).
1
13 Carrying Case
A textile bag used for the transportation and storage of the Bit and its accessories.
1
