13
ITEM BIT 5X BIT 5X-10X
Display Brightness Discretely Adjustable to 8 Levels
Turn-on Time, max 3 sec
Analog Input Format PAL/ NTSC
Analog Output Format PAL
PAL Output Resolution 768×574 pixels
TABLE 2-3. MECHANICAL DATA
ITEM BIT 5X BIT 5X-10X
Overall Dimensions 240Ч69Ч65mm (9.4”Ч2.7”Ч2.6“) 335Ч70Ч74mm (13.2”Ч2.8”Ч2.9“)
Weight (w/o Batteries) 0.74 kg (1.6 lbs) 1.07 kg (2.4 lbs)
TABLE 2-4. OPTICAL DATA
ITEM BIT 5X BIT 5X-10X
Magnification 5x
(10x with optional
Afocal Doubler)
5x or 10x
(10x with included
Afocal Doubler)
Field of View - ang. X degrees 5.7° 3.2° (with Afocal Doubler)
- ang. Y degrees 4.2° 2.3° (with Afocal Doubler)
Objective Focal Length 50mm 90mm (with Afocal Doubler)
Objective F-number 1:1.2 1:1.4 (with Afocal Doubler)
Eyepiece Focal Length 25 mm
Entrance Pupil Diameter 42mm 65mm
Exit Pupil Diameter 10 mm
Eye Relief 45 mm
Focus Method Manual
Focusing Range 10m to infinity 10m to infinity
Diopter Adjustment Manual
Diopter Adjustment Range ±5 diopter
TABLE 2-5. ELECTRICAL DATA
ITEM DATA
Battery Two CR123A Lithium 3V or CR123 type
rechargeable batteries with voltage 3.2V
Current Consumption, maximum 500 mA
Battery Life at 20 °C (68 °F) up to 3 hr
External Battery Power Supply 1 Four AA Lithium batteries (1.5V) or AA recharge-
able batteries (1.2V) / Operational Time up to
3.5 hr
External Battery Power Supply 2 Two 18650 rechargeable batteries (3.7V) or four
CR123 type rechargeable batteries with voltage
3.7V max. / Operational Time up to 7 hr
External Power Supply 6 VDC / 1 А
TABLE 2-2. CONTINUED
