Analytical Industries GPR-2800 AIS ATEX Oxygen Analyzer - Manual (Page 28)

Advanced Instruments Inc.
28
23. Press the ENTER key to advance the underline cursor right or press the MENU key to advance the underline cursor left to
reach to the desired digit of the alarm value.
24. Press the ARROW keys to enter the alarm value.
25. Repeat until the complete span value has been entered.
26. Save the adjustment value by pressing the ENTER key or abort by pressing the MENU key.
27. Allow approximately 60 seconds for the calibration process while the processor determines whether the signal output or
reading has stabilized within 60% of the full scale low range. Both the Zero Calibrate and Span Calibrate functions result in
the following displays:
PASSED
CALIBRATION
OR
FAILED
CALIBRATION
28. If the calibration is successful, the transmitter returns to the SAMPLING mode after 30 seconds.
29. If the calibration is unsuccessful, return to the SAMPLING mode with span gas flowing through the transmitter, make sure
the reading stabilizes and repeat the calibration before concluding the equipment is defective.
30. Before disconnecting the span gas line and connecting the sample gas line, restart if necessary the flow of sample gas and
allow it to flow for 1-2 minutes to purge the air inside the line.
31. Disconnect the span gas line and replace it with the purged sample gas line.
32. Wait 10-15 minutes to ensure the reading is stable and proceed to sampling.
Default Span
The software will set the SPAN adjustment based on the average oxygen reading (actually the sensor’s signal output) at any
specific oxygen concentration. For example, when a span gas is introduced, the micro-processor will display an oxygen reading
within +50% of the span gas value. This feature allows the user to test the sensor’s signal output without removing it from the
sensor housing.
1. Access the MAIN MENU by pressing the MENU key.
2. Advance the reverse shade cursor using the ARROW keys to highlight CALIBRATION.
3. Press the ENTER key to select the highlighted menu option.
4. The following displays appears:
MAIN MENU
AUTO SAMPLE
MANUAL SAMPLE
CALIBRATION
CONFIG ALARMS
BYPASS ALARMS
>>>
CALIBRATION
SPAN CALIBRATE
ZERO CALIBRATE
DEFAULT SPAN
DEFAULT ZERO
OUTPUT SPAN
OUTPUT ZERO
5. Advance the reverse shade cursor using the ARROW keys to highlight DEFAULT SPAN.
6. Press the ENTER key to select the highlighted menu option.
7. The following displays appear and after 3 seconds the system returns to the SAMPLING mode:
