Air Suspension C-2145 REV 4 User Manual
Page 15
15
REV
4
06/24/2014
C-2145
C-2145
ARNOTT COIL SPRING CONVERSION KIT
FOR
2006-2012
LAND ROVER RANGE ROVER
11.
USING A FLOOR JACK, RAISE THE LOWER CONTROL ARM TO REALIGN WITH THE SPINDLE BEING
SURE THE SPRING IS SECURELY SEATED. REINSTALL THE LOWER CONTROL ARM TO SPINDLE BOLT
FOLLOWED BY THE REMAINING SUSPENSION FASTENERS. (FIGURE 40-11)
12.
INSTALLATION COMPLETE.
FIGURE 40-11
