Air Suspension C-2145 REV 4 User Manual
Page 11
11
REV
4
06/24/2014
C-2145
C-2145
ARNOTT COIL SPRING CONVERSION KIT
FOR
2006-2012
LAND ROVER RANGE ROVER
13.
REMOVAL COMPLETE. (FIGURE 30-6)
FIGURE 30-6
FIGURE 40-1
REAR COIL SPRING INSTALLATION
1.
REMOVE THE LOWER SHOCK BOLT.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
