ASUS M2V-MX SE 2-33
CPU Temperature [xxx ºC/xxx ºF] or [Ignored]
MB Temperature [xxx ºC/xxx ºF] or [Ignored]
The onboard hardware monitor automatically detects and displays the CPU,
motherboard and power temperatures. Select Ignored if you do not wish to display
the detected temperatures.
CPU Fan Speed [xxxxRPM] or [Ignored]
The onboard hardware monitor automatically detects and displays the CPU fan speed
in rotations per minute (RPM). If the fan is not connected to the chassis, the specific field
shows N/A. Select Ignored if you do not wish to display the detected speed.
Chassis Fan Speed [xxxxRPM] or [N/A] or [Ignored]
The onboard hardware monitor automatically detects and displays the chassis fan speed
in rotations per minute (RPM). If the fan is not connected to the chassis, the specific field
shows N/A. Select Ignored if you do not wish to display the detected speed.
VCORE Voltage, +3.3V Voltage, +5V Voltage, +12V Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
Smart Q-Fan function [Disabled]
Allows you to enable or disable the smart Q-fan control function. When this field is
set to [Enabled], the item Fan Auto Mode.items.appear.
Configuration options: [Disabled] [Enabled]
Fan Auto Mode Start Voltage, Start Speed Temp, Full Speed Temp
Sets the smart fan mode.
2.5.5 Hardware Monitor
Hardware Monitor
CPU Temperature [43ºC/93ºF]
MB Temperature [35ºC/95ºF]
CPU Fan Speed [3308RPM]
Chassis Fan Speed [N/A]
VCORE Voltage [ 1.504V]
3.3V Voltage [ 3.360V]
5V Voltage [ 5.160V]
12V Voltage [11.328V]
Smart Q-Fan Function [Disabled]
CPU Temperature
