ROG RAMPAGE III BLACK EDITION 3-13
�.�.�4 Memory Configuration Protect [Disabled]
Allows you to lock or unlock the memory configuration.
Configuration options: [Enabled] [Disabled]
3.3.15 DRAM Timing Control
The sub-items in this menu allow you to set the DRAM timing control features. Use
the <+> and <-> keys to adjust the value. To restore the default setting, type [auto]
using the keyboard and press the key.
Changing the values in this menu may cause the system to become unstable! If
this happens, revert to the default settings.
3.3.16 CPU QPI Strength [Auto]
Allows you to select the CPU QPI strength.
Configuration options: [Auto] [Typical Sweet Spot] [Normal] [Weaker]
3.3.17 ALT QPI Strength [Auto]
Allows you to select the ALT QPI strength.
Configuration options: [Auto] [Typical Sweet Spot] [Normal] [Weaker]
3.3.18 First 2 Slots PCIE Strength [Auto]
Allows you to set the first two slots PCIE strength. The values range from
0.80825V to 1.51050V with a 0.01325V interval.
3.3.19 Last 2 Slots PCIE Strength [Auto]
Allows you to set the last two slots PCIE strength. The values range from 0.80825V
to 1.51050V with a 0.01325V interval.
3.3.20 CPU Differential Amplitude [Auto]
Different AMP might enhance BCLK overclocking ability.
Configuration options: [Auto] [700mV] [800mV] [�00mV] [1000mV]
3.3.21 CPU Clock Skew [Auto]
Adjusting this item may help enhancing BCLK overclocking ability. You may need
to adjust the IOH Clock Skew item at the same time.
Configuration options: [Auto] [Normal] [Delay 100ps]–[Delay 1500ps]
3.3.22 IOH Clock Skew [Auto]
Adjusting this item may help enhancing BCLK overclocking ability. You may need
to adjust the CPU Clock Skew item at the same time.
Configuration options: [Auto] [Normal] [Delay 100ps]–[Delay 1500ps]
