3-28 Chapter 3: BIOS setup
3.5.6 LCD Poster and LED Control
LCD Poster Backlight [Turn Off]
Allows you to turn on/off the LCD Poster backlight when the system is working.
Configuration options: [Turn On] [Turn Off]
LCD Poster Backlight (S5) [Turn Off]
Allows you to turn on/off the LCD Poster backlight when the system is in soft-off
state. Configuration options: [Turn Off] [Turn On]
LCD Poster Mode [Current Time]
Allows the LCD Poster to display either hardware information or time.
Configuration options: [Current Time] [HWM Information]
The following item becomes configurable when you set LCD Poster Mode to
[HWM Information].
HWM Select Mode
Allows you to select which hardware information to display on the LCD
Poster. Configuration options: [All Voltage] [All Temperature] [All Fan Speed]
All LED Control [Enabled]
Allows you to enable or disable the onboard LEDs control.
Configuration options: [Enabled] [Disabled]
The following items appear only when you set All LED Control to [Enabled].
Voltiminder LED [Enabled]
Allows you to enable or disable the onboard Voltiminder LED.
Configuration options: [Enabled] [Disabled]
The following items appear only when you set Voltiminder LED to [Enabled].
BIOS SETUP UTILITY
Advanced
LCD Poster and LED Control
LCD Poster Backlight [Turn Off]
LCD Poster Backlight(S5) [Turn Off]
LCD Poster Mode [Current Time]
All LED Control [Enabled]
Voltiminder LED [Enabled]
CPU LED Selection [CPU]
NB LED Selection [IOH]
SB LED Selection [ICH]
Turn On/Turn Off LCD
Poster when system
is working
