xiii
USB 12 x USB 2.0 ports (6 ports at midboard; 6 ports at back
panel)
ROG Exclusive
Overclocking Features
Power Design
- 8-phase CPU power
- 2-phase QPI/DRAM power
- 2-phase NB power
- 2-phase Memory power
CPU Level Up
Keyboard-Tweakit (adjustable frequency at 0.2MHz
increment)
Memory Level Up
iROG
Extreme Tweaker
Loadline Calibration
Intelligent overclocking tools:
- ASUS AI Booster Utility
- ASUS O.C. Profile ASUS O.C. Profile O.C. Profile
Overclocking Protection:
- COP EX (Component Overheat Protection - EX)
- Voltiminder LED
- ASUS C.P.R. (CPU Parameter Recall)
Other Special Features MemOK!
One DIMM latch
External LCD Poster
Onboard Switches: Power / Reset / Clr CMOS (at back
panel)
Q-Fan Plus
ASUS EPU-6 Engine
ASUS Fan Xpert
ASUS Q-Connector
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS MyLogo 3™
BIOS Features 16 Mb AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 2.4,
ACPI 2.0a, Multi-Language BIOS
Manageability WOL by PME, WOR by PME, Chassis Intrusion, PXE
Back Panel I/O Ports 1 x PS/2 Keyboard port (purple)
1 x S/PDIF (Optical)
1 x External SATA port
1 x IEEE1394a port
1 x LAN (RJ45) port
6 x USB 2.0/1.1 ports
1 x Clr CMOS switch
8-channel Audio I/O with gold-plated jack
(continued on the next page)
Rampage II GENE specifications summary
