ROG Rampage II GENE 3-9
3.3 Extreme Tweaker menu
The Extreme Tweaker menu items allow you to configure overclocking-related
items.
Take caution when changing the settings of the Extreme Tweaker menu items.
Incorrect field values can cause the system to malfunction.
The default values of the following items vary depending on the CPU and
memory modules you install on the motherboard.
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
BIOS SETUP UTILITY
Extreme Tweaker Main Advanced Power Boot Tools Exit
Tuning Mode is the
BIOS menu switch for
different purpose.
Extreme OC offers
the max tuning degree
of freedom to the
extreme.
Gaming provides the
major tuning settings
for system
performance boot.
←→ Select Screen
↑↓ Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Configure System Performance Settings
Target CPU Frequency: 2660MHz
Target DRAM Frequency: 1066MHz
Tuning Mode [Extreme OC]
CPU Level Up [Auto]
Memory Level Up [Auto]
Ai Overclock Tuner [Auto]
Ratio Status:(Min:12, Max: 20)
Ratio Actual Value:20
CPU Ratio Setting [Auto]
CPU Configuration
DRAM Frequency [Auto]
DRAM Timing Control
EPU II Phase Control [Full Phase]
CPU Load-Line Calibration [Auto]
QPI Load-Line Calibration [Disabled]
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
CPU Differential Amplitude [Auto]
NB OCP [Enabled]
DRAM OCP [Enabled]
*** Please key in numbers or select voltage! ***
Extreme OV [Disabled]
Current Voltage: 1.184V 1.819V 1.230V
CPU Temperature: 43.5˚C/110˚F
CPU Voltage [Auto]
CPU PLL Voltage [Auto]
QPI/DRAM Core Voltage [Auto]
Current Voltage: 1.085V 1.508V 1.111V 1.508V
NB/SB Temperature: 45˚C/113˚F 52˚C/125.5˚F
IOH Voltage [Auto]
IOH PCIE Voltage [Auto]
ICH Voltage [Auto]
ICH PCIE Voltage [Auto]
Current Voltage: 1.508V
DRAM Bus Voltage [Auto]
DRAM REF Voltages
Read POST Code from LCD Poster/iROG Control Plus
Debug Mode [String]
Keyboard TweakIt Control [Disabled]
******** Spread Spectrum and Clock Skew ********
CPU Spread Spectrum [Auto]
PCIE Spread Spectrum [Auto]
CPU Clock Skew [Auto]
IOH Clock Skew [Auto]
Scroll down to display the following items:
