Asus Rampage II Gene - Manual (Page 31)

2.2.2 Layout contents
Connectors/Jumpers/Switches/Slots Page
1. CPU, chassis, and optional fan connectors (4-pin CPU_FAN;
3-pin CHA_FAN1–2; 3-pin OPT_FAN1–2)
2-35
2. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-37
3. LGA1366 CPU Socket 2-10
4. DDR3 DIMM slots 2-15
5. IDE connector (40-1 pin PRI_EIDE) 2-30
6. ICH10R Serial ATA connectors (7-pin SATA1–6 [blue]) 2-31
7. JMicron JMB363 ® Serial ATA connector (7-pin SATA_E1 [black]) 2-32
8. Clear RTC RAM (3-pin CLRTC_SW) 2-27
9. System panel connector (20-8 pin PANEL) 2-38
10. USB connectors (10-1 pin USB78; USB910; USB1112) 2-32
11. MemOK! switch 2-41
12. Reset switch 2-40
13. Power-on switch 2-40
14. Thermal sensor cable connectors (2-pin OPT_TEMP1–2) 2-36
15. Chassis intrusion connector (4-1 pin CHASSIS) 2-36
16. Digital audio connector (4-1 pin SPDIF_OUT) 2-33
17. IEEE 1394a port connector (10-1 pin IE1394_2) 2-33
18. Optical drive audio connector (4-pin CD) 2-34
19. Front panel audio connector (10-1 pin AAFP) 2-34
Refer to 2.7 Connectors for more information about rear panel connectors and
internal connectors.
