ROG Rampage II GENE 3-25
3.5.3 Onboard Device Configuration
Onboard Device [Standard]
Allows you to disable all the onboard device controllers except the LAN controller.
Configuration options: [Standard] [Disabled]
High Definition Audio [Enabled]
Allows you to enable or disable the High Definition Audio Controller.
Configuration options: [Enabled] [Disabled]
Front Panel Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy
AC’97 or high-definition audio depending on the audio standard that the front
panel audio module supports. Configuration options: [AC97] [HD Audio]
J-Micron eSATA/PATA Controller [Enabled]
Allows you to enable or disable the onboard JMicron eSATA/PATA controller.
Configuration options: [Enabled] [Disabled]
Controller Mode [IDE]
This item appears only when you enable the previous item.
Configuration options: [IDE] [AHCI]
If you want to use the hard disk drive as a Parallel ATA physical storage
device, keep the defaul setting [IDE].
If you want the hard disk drive to use the Advanced Host Controller Interface
(AHCI), set this item to [AHCI].
Realtek LAN [Enabled]
Allows you to enable or disable the onboard LAN controller.
Configuration options: [Enabled] [Disabled]
Onboard LAN Boot ROM [Disabled]
This item appears only when you enable the previous item.
Configuration options: [Disabled] [Enabled]
BIOS SETUP UTILITY
Advanced
Onboard Device Configuration
Onboard Device [Standard]
High Definition Audio [Enabled]
Front Panel Type [HD Audio]
J-Micron eSATA/PATA Controller [Enabled]
Controller Mode [IDE]
Realtek LAN [Enabled]
LAN Boot ROM [Disabled]
Onboard 1394 Controller [Enabled]
Get your best
overclocking record!
“Onboard Device” is
to disable all the
unnecessary devices
when you want to
reach you best
overclocking record.
But it will keep 1
lan port alive to
submit your score.
