4.4.6

Onboard Devices Configuration

HD Audio Controller [Enabled]

Allows you to enable or disable the high-definition audio CODEC.
Configuration options: [Enabled] [Disabled]

Front Panel Support Type [HD Audio]

Allows you to set the front panel audio connector (AAFP) mode to legacy
AC‘97 or high–definition audio [HD Audio] depending on the audio standard
that the front panel audio module supports. Configuration options: [AC97]
[HD Audio]

OnBoard PCIEX GbE LAN [Enabled]

Allows you to enable or disable the onboard PCI Express Gigabit LAN
controller. Configuration options: [Disabled] [Enabled]

Configure Win627EHF Super IO Chipset

HD Audio Controller

[Enabled]

Front Panel Support Type

[HD Audio]

Onboard PCIEX GbE LAN

[Enabled]

LAN Option ROM

[Disabled]

ITE8211F Controller

[IDE Mode]

Detecting Device Time

[Quick Mode]

Serial Port1 Address

[3F8/IRQ4]

Parallel Port Address

[378]

Parallel Port Mode

[ECP]

ECP Mode DMA Channel

[DMA3]

Parallel Port IRQ

[IRQ7]

Onboard Game/MIDI Port

[Disabled]

Enable or disable
High Definition Audio
Controller.

Slot Power [Auto]

Sets the PCI Express graphics card slot power.
Configuration options: [Auto] [Light] [Normal] [Heavy] [Heavier]

High Priority Port Select [Disabled]

Allows you to disable or select the high priority port. The specified high
priority port will be given arbitration above VC0 but below VC1.
Configuration options: [Disabled] [PCI Express Port 1] [PCI Express Port 2]
[PCI Express Port 3]

PEG Link Mode [Auto]

Sets the PCI Express graphics link mode. Setting this item to [Auto] allows
the motherboard to automatically adjust the PCI Express graphics link mode
to the correct frequency based on the system configuration. Four
additional settings are available for overclocking the PEG Link Mode.
Configuration options: [Auto] [Slow] [Normal] [Fast] [Faster]
