2 - 2 0 2 - 2 0 2 - 2 0 2 - 2 0 2 - 2 0 C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n
2.5.4 2.5.4 2.5.4 2.5.4 2.5.4 PCI slots PCI slots PCI slots PCI slots PCI slots
2.5.6 2.5.6 2.5.6 2.5.6 2.5.6 PCI Express x16 slot PCI Express x16 slot PCI Express x16 slot PCI Express x16 slot PCI Express x16 slot
This motherboard supports PCI Express x16 graphic cards that comply with
the PCI Express specifications.
2.5.5 2.5.5 2.5.5 2.5.5 2.5.5 PCI Express x1 PCI Express x1 PCI Express x1 PCI Express x1 PCI Express x1
slot slot slot slot slot
This motherboard supports PCI
Express x1 network cards, SCSI
cards and other cards that comply
with the PCI Express specifications.
The figure shows a network card
installed on the PCI Express x1 slot.
The figure shows a graphics card
installed on the PCI Express x16
slot. The figure shows an optional
DVI-ADD2 card installed on the
PCI-Express x16 slot. A DVI-ADD2
card supports digital video output.
The PCI slots support cards such as a
LAN card, SCSI card, USB card, and
other cards that comply with PCI
specifications. The figure shows a
LAN card installed on a PCI slot.
