ASUS P5E-VM HDMI 2-27
• Pin 20 on the IDE connector is removed to match the covered hole on the
Ultra DMA cable connector. This prevents incorrect insertion when you
connect the IDE cable.
• Use the 80-conductor IDE cable for Ultra DMA 133/100/66 IDE devices.
If any device jumper is set as “Cable-Select,” make sure all other device
jumpers have the same setting.
3. ICH9R Serial ATA connectors
(7-pin SATA1 [red], SATA2 [red], SATA3 [black], SATA4 [black], SATA5
[red], SATA6 [red])
These connectors are for the Serial ATA signal cables for Serial ATA hard disk
drives.
If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1,
RAID 5, and RAID 10 configuration with the Intel
® Matrix Storage Technology
through the onboard Intel ® ICH9R RAID controller.
P
5
E
-V
M
H
D
M
I
®
P5E-VM HDMI SATA connectors
SATA1
GND RS
A
TA_TXP1
RS
A
TA_TXN1
GND RS
A
TA_RXP1
RS
A
TA_RXN1
GND
SATA3
GND RS
A
TA_TXP3
RS
A
TA_TXN
3
GND RS
A
TA_RXP
3
RS
A
TA_RXN3
GND
GND RS
A
TA_TXP5
RS
A
TA_TXN5
GND RS
A
TA_RXP
5
RS
A
TA_RXN5
GND
SATA5
SATA2
GND RS
A
TA_TXP2
RS
A
TA_TXN2
GND RS
A
TA_RXP
2
RS
A
TA_RXN2
GND
SATA4
GND RS
A
TA_TXP4
RS
A
TA_TXN
4
GND RS
A
TA_RXP
4
RS
A
TA_RXN4
GND
GND RS
A
TA_TXP6
RS
A
TA_TXN6
GND RS
A
TA_RXP
6
RS
A
TA_RXN6
GND
SATA6
• These connectors are set to Standard IDE mode by default. In Standard
IDE mode, you can connect Serial ATA boot/data hard disk drives to these
connectors. If you intend to create a Serial ATA RAID set using these
connectors, set the
Configure SATA as item in the BIOS to [RAID]. See
section 4.3.6 SATA Configuration for details.
• Before creating a RAID set, refer to 5.4.3 Intel RAID Configuration or the
manual bundled in the motherboard support CD.
