ASUS P5E-VM HDMI 5-37
Creating a RAID 1 set (mirrored)
To create a RAID 1 set:
1. From the utility main menu, select 1. Create RAID Volume, then press
. This screen appears.
2. Enter a name for the RAID 1 set, then press .
3.
When the RAID Level item is highlighted, press the up/down arrow key to
select RAID 1(Mirror), then press .
4. When the Capacity item is highlighted, key in the RAID volume capacity that
you want, then press . The default value indicates the maximum
allowed capacity.
5. Press when the Create Volume item is highlighted. This warning
message appears.
Intel(R) Matrix Storage Manager Option ROM v5.0.0.1032 ICH9R wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can be used
to uniquely identify the RAID volume. This name is case sensitive and
cannot contain special characters.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [Enter]-Select
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume1
RAID1(Mirror)
Select Disks
N/A
XX.X GB
Create Volume
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
6. Press to create the RAID volume and return to main menu or to go
back to Create Volume menu.
