ASUS M4A78T-E 3-27
Chapter 3
3.7.6 Hardware Monitor
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
CPU Temperature
CPU/MB Temperature [xxx�C/xxx�F] [xxx�C/xxx�F]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignored if you do not wish to display the detected temperatures.
CPU Fan /Chassis Fan 1 and 2 Speed [xxxxRPM] or [Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the CPU and chassis fan
speed in rotations per minute (RPM). If the fan is not connected to the motherboard, the field
shows N/A. Select Ignored if you do not wish to display the detected speed.
VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators. Select Ignored if you do not want to detect this item.
CPU Q-Fan Function [Disabled]
[Disabled] Disables the CPU Q-Fan control feature. Q-Fan control feature..
[Enabled] Enables the CPU Q-Fan control feature. Q-Fan control feature..
The following two items appear only when you set CPU Q-Fan Function to [Enabled].
Select Fan Type: [PWR Fan]
[PWR Fan] Sets to [PWR Fan] when using a 4-pin CPU fan.
[DC Fan] Sets to [DC Fan] when using a 3-pin CPU fan. Sets to [DC Fan] when using a 3-pin CPU fan..
Quiet CPU Fan Mode [Silent]
[Performance] Sets to [Performance] to achieve maximum CPU fan speed.
[Optimal] Sets to [Optimal] to make the CPU fan automatically adjust
depending on the CPU temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet CPU fan
operation.
BIOS SETUP UTILITY
Power
Hardware Monitor
CPU Temperature [42ºC/107.5ºF]
MB Temperature [33ºC/91ºF]
CPU Fan Speed [4856RPM]
Chassis Fan 1 Speed [N/A]
Chassis Fan 2 Speed [N/A]
VCORE Voltage [ 1.234V]
3.3V Voltage [ 3.320V]
5V Voltage [ 5.026V]
12V Voltage [11.787V]
CPU Q-Fan Function [Disabled]
Chassis Q-Fan Function [Disabled]
