ASUS M4A78T-E 3-23
Chapter 3
The following item appears only when you set the HD Audio Azalia Device item to
[Enabled].
Front Panel Type [HD]
[AC 97] Sest the front panel audio connector (AAFP) mode to legacy AC’97.
[HD] Sets the front panel audio connector (AAFP) mode to high definition audio.
Onboard LAN [Enabled]
[Enabled] Enables the onboard LAN controller.
[Disabled] Disables the onboard controller.
The following item appears only when you set the Onboard LAN item to [Enabled].
Onboard LAN Boot ROM [Disabled]
[Enabled] Enables the onboard LAN Boot ROM.
[Disabled] Disables the onboard LAN Boot ROM.
Firewire 1394 [Enabled]
[Enabled] Enables the onboard 1394 device support.
[Disabled] Disables the onboard 1394 device support. onboard 1394 device support.
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
3.6.4 USB Configuration
The items in this menu allows you to change the USB-related features. Select an item then
press to display the configuration options.
USB Configuration
Module Version - 2.24.3-13.4
USB Devices Enabled:
None
USB Support [Enabled]
Legacy USB Support [Enabled]
USB 2.0 Controller [Enabled]
USB 2.0 Controller Mode [HiSpeed]
BIOS EHCI Hand-Off [Enabled]
Enable support for
all USB ports.
BIOS SETUP UTILITY
Advanced
The USB Devices Enabled item shows the auto-detected values. If no USB device is
detected, the item shows None.
USB Functions [Enabled]
[Enabled] Enables the USB Host Controllers.
[Disabled] Disables the controllers.
The following items appear only when you set USB Support to [Enabled].
