Page 67

ASUS M4A78T-E

3-9

Chapter 3

Primary IDE Master

Device : Hard Disk

Vendor : WDC WD800JD-00LSA0

Size : 80.0GB

LBA Mode : Supported

Block Mode : 16 Sectors

PIO Mode : 4

Async DMA : MultiWord DMA-2

Ultra DMA : Ultra DMA-5

SMART Monitoring: Supported

Type

[Auto]

LBA/Large Mode

[Auto]

Block(Multi-sector Transfer)M [Auto]

PIO Mode

[Auto]

DMA Mode

[Auto]

SMART Monitoring

[Auto]

32Bit Data Transfer

[Enabled]

3.4

Main menu

When you enter the BIOS Setup program, the Main menu screen appears, giving you an

overview of the basic system information. You can set the system time and date, BIOS

language, and the type of floppy drive installed.

Refer to 3.3.1 BIOS menu screen for information on the menu screen items and how to

navigate through them.

Select Screen

Select Item

Change Field

Tab Select Field

F1 General Help

F10 Save and Exit

ESC Exit

BIOS SETUP UTILITY

Main

Ai Tweaker Advanced Power Boot Tools Exit

System Time

[10:55:25]

System Date

[Tue 12/09/2008]

8]]

Legacy Diskette A

[1.44M, 3.5 in.]

Language

[English]

Primary IDE Master

[Not Detected]

Primary IDE Slave

[Not Detected]

SATA1

[HDT722516DLA380]

SATA2

[Not Detected]

Not Detected]]

SATA3

[Not Detected]

SATA4

[Not Detected]

SATA5

[Not Detected]

ESATA

[Not Detected]

Storage Configuration

System Information

Use [ENTER], [TAB]

or [SHIFT-TAB] to

select a field.

Use [+] or [-] to

configure the System

Time.

3.4.1

Primary IDE Master/Slave; SATA 1-5; ESATA

SATA 1-5; ESATA

While entering Setup, the BIOS automatically detects the presence of IDE/SATA devices.

There is a separate submenu for each IDE/SATA device. Select a device item then press

to display the SATA device information.

Select Screen

Select Item

+- Change Option

F1 General Help

F10 Save and Exit

ESC Exit

BIOS SETUP UTILITY

Main

Select the type of

device connected to

the system.

The BIOS automatically detects the values opposite the dimmed items (Device, Vendor, Size,

LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra DMA, and SMART monitoring). These

values are not user-configurable. These items show N/A if no IDE device is installed in the

system.
