Asus GigaX1104PS - Manual (Page 14)

13
GigaX1104PS User's Manual
2.2.2 For Windows® 2000 PCs:
Firstly, Search for the IP protocol and, if necessary, install it:
1. In the Windows task bar, click the button, point to
Settings, and then click Control Panel.
2. Double-click the Network and Dial-up Connections icon.
3. In the Network and Dial-up Connections window, right-click
the Local Area Connection icon, and then select Properties.
The Local Area Connection Properties dialog box displays a
list of currently installed network components. If the list includes
Internet Protocol (TCP/IP), then the protocol has already been
enabled. Please skip to step 10.
4. If Internet Protocol (TCP/IP) is not displayed as an installed
component, click button.
5. In the Select Network Component Type dialog box, select
Protocol, and then click button.
6. Select Internet Protocol (TCP/IP) in the Network Protocols
list, and then click button.
You may be prompted to install files from your Windows 2000
installation CD or other media. Follow the instructions to install
the files.
7. If prompted, click button to restart your computer with
the new settings.
Secondly, configure a static IP address for your PC:
8. In the Control Panel, double-click the Network and Dial-up
Connections icon.
9. In Network and Dial-up Connections window, right-click
the Local Area Connection icon, and then select Properties.
10. In the Local Area Connection Properties dialog box,
select Internet Protocol (TCP/IP), and then click
button.
