ROG MAXIMUS V GENE 3-15
Chapter 3
DO NOT remove the thermal module. The thermal conditions must be
monitored.
VCCIO
The sub-items in this menu allow you to set the VCCIO settings.
VCCIO Switching Freq [Auto]
Allows you to switch the VCCIO frequency
Configuration options: [Auto] [1X] [1.65X]
VCCIO Full Phase Control [Enabled]
Allows you to enable or disable the VCCIO Full Phase Control.
Configuration options: [Auto] [Disabled] [Enabled]
VCCIO Over-Current Protection [Enabled]
Allows you to enable or disable the VCCIO Over-Current Protection.
Configuration options: [Disabled] [Enabled]
Extreme OV [Disable]
This item is set to [Disabled] by default to protect the CPU from being overheated.
Set this item to [Enabled] to choose a higher voltage to overclock, but doing so
might decrease CPU life. Configuration options: [Disabled] [Enabled]
CPU Voltage [Offset Mode]
[Manual Mode] Allows you to set a fixed CPU voltage.
[Offset Mode] Allows you to set the Offset voltage.
CPU Manual Voltage [Auto]
This item appears only when you set the CPU Voltage item to [Manual Mode]
and allows you to set a fixed CPU voltage. The values range from 0.800V to
2.155V with a 0.005V interval. The 2.155V voltage is available only when the
Extreme OV item is set to [Enabled].
Offset Mode Sign [+]
This item appears only when you set the CPU Voltage item to [Offset Mode].
[+]
To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Offset Voltage [Auto]
This item appears only when you set the CPU Voltage item to [Offset Mode]
and allows you to set the Offset voltage. The values range from 0.005V to
0.635V with a 0.005V interval.
