Configuring Firewall RX3042H User's Manual
80
9.7 Configure Virtual Server
Virtual server allows you to configure up to ten public servers, such
as a Web, E-mail, FTP server and etc. accessible by external users
of the Internet. Each service is provided by a dedicated server
configured with a fixed IP Address. Although the internal service
addresses are not directly accessible to the external users the
router is able to identify the service requested by the service port
number and redirects the request to the appropriate internal server.
Note: RX3042H supports only one server of any
particular type at a time.
9.6.4 View Configured Self-Access Rules
To see existing Self-Access Rules, just open the Self-Access ACL
configuration page by clicking Firewall/NAT ->Self-Access ACL
menu.
Figure 9.9. Virtual Server Configuration Page
9.7.1 Virtual Server Configuration Parameters
Table 9.5 describes the configuration parameters available for
