Quick Start Guide RX3042H User's Manual
16
Protocol, and then click < Add> button.
5. Select Microsoft in the Manufacturers list box, and then click
TCP/IP in the Network Protocols list, box and then click < OK>
button.
You may be prompted to install files from your Windows 95, 98
or Me installation CD or other media. Follow the instructions to
install the files.
6. If prompted, click button to restart your computer with the
new settings.
Next, configure the PCs to accept IP information assigned by
the RX3042H:
7. In the Control Panel, double-click the Network icon.
8. In the Network dialog box, select an entry started with “
TCP/
IP ->” and the name of your network adapter, and then click
< Properties> button.
9. In the TCP/IP Properties dialog box, click the radio button
labeled Obtain an IP address automatically.
10.In the TCP/IP Properties dialog box, click the “ Default
Gateway” tab. Enter 192.168.1.1 (the default LAN port IP
address of the RX3042H) in the “ New gateway” address field
and click < Add> button to add the default gateway entry.
11. Click < OK> button twice to confirm and save your changes,
and then close the Control Panel.
12. If prompted to restart your computer, click < OK> button to do
so with the new settings.
3.2.5 Windows® NT 4.0 workstations:
First, check for the IP protocol and, if necessary, install it:
1. In the Windows NT task bar, click the < Start> button, point to
Settings, and then click Control Panel.
2. In the Control Panel window, double click the Network icon.
3. In the Network dialog box, click the Protocols tab.
The Protocols tab displays a list of currently installed network
