Asus RX3042H - Manual (Page 88)

Configuring Firewall RX3042H User's Manual
76
Figure 9.5. ACL Configuration Example
explanation of these fields.
8. Assign a priority for this rule by selecting a number from the
Move to drop-down list. Note that the number indicates the
priority of the rule with 1 being the highest. Higher priority rules
will be examined prior to the lower priority rules by the firewall.
9. Click on the Add button to create the new ACL rule. The new
ACL rule will then be displayed in the inbound access control list
table at the bottom half of the Inbound ACL Configuration page.
Figure 9.5 illustrates how to create a rule to deny outbound HTTP
traffic originated from the host w/ IP address 192.168.1.129.
Figure 9.6. Sample ACL List Table
