RX3042H User's Manual Router Setup
37
by the DHCP server of your ISP.
4. (Optional) Change the MTU value if necessary. If you do
not know what value to enter, leave it as is. For dynamic IP
connection mode, the range of MTU is from 546 to 1500. The
default value is 1500.
5. Click Apply"to save the settings.
5.2.5 Static IP
Figure 5.6. WAN – Static IP Configuration
5.2.5.1 WAN or DMZ Static IP Configuration Parameters
Table 5.4 describes the configuration parameters available for static
IP connection mode.
Table 5.4. WAN Static IP Configuration Parameters
Setting Description
Link
Select a port to configure. Available options are
WAN1/WAN2 or WAN/DMZ.
Connection
Mode
Select Static from the connection mode drop-
down list.
IP Address
WAN IP address provided by your ISP. For
DMZ mode, typically, it is a private IP address.
