Page 74
3-16
Chapter 3: BIOS setup
Chapter 3
TWTR [Auto]
Configuration options: [Auto] [4 CLK] [5 CLK] [6 CLK] [7 CLK]
TWRWR [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] – [10 CLK]
TRDRD [Auto]
Configuration options: [Auto] [2 CLK] [3 CLK] [4 CLK] – [10 CLK]
TRFC0/TRFC01 [Auto]
Configuration options: [Auto] [90ns] [110ns] [160ns] [300ns] [350ns]
DCT0:CKE drive strength. [Auto]
DCT1:CKE drive strength. [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
DCT0:CS/ODT drive strength. [Auto]
DCT1:CS/ODT drive strength. [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
DCT0:Address/Command drive str [Auto]
DCT1:Address/Command drive str [Auto]
Configuration options: [Auto] [1x] [1.25x] [1.5x] [2x]
DCT0:MEMCLK drive strength. [Auto]
DCT1:MEMCLK drive strength. [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
DCT0:Data drive strength. [Auto]
DCT1:Data drive strength. [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
DCT0:DQS drive strength. [Auto]
DCT1:DQS drive strength. [Auto]
Configuration options: [Auto] [0.75x] [1x] [1.25x] [1.5x]
DCT0:Processor on-die terminat [Auto]
DCT1:Processor on-die terminat [Auto]
Configuration options: [Auto] [240 ohms +/- 20%] [120 ohms +/- 20%] [60 ohms +/- 20%]
3.5.10
CPU Voltage [Auto]
Allows selection of the processor Voltage. The values range from 0.8000V to 1.90V* with a
The values range from 0.8000V to 1.90V* with a
0.0125V interval.
•
The value [1.90V] is supported only if the
The value [1.90V] is supported only if the OV_CPU jumper is enabled. Otherwise,
the maximum voltage supported is [1.70V]. See 2. CPU overvoltage setting on page
2-21 for details.
•
The supported voltage may vary by CPU models.
