ASUS M4A79T Deluxe 4-15
Chapter 4
The Main Menu above allows you to select an operation to perform. The Main Menu options
include:
• View Drive Assignments: shows the status of the hard disk drives.
• Define LD: creates a RAID 0, RAID 1, RAID 5 or RAID 10 configuration.
• Delete LD: deletes a selected RAID set and partition.
• Controller Configuration: Shows the system resources configuration.
Press <1>, <2>, <3>, or <4> to enter the option you need; press to exit the utility.
FastBuild (tm) Utility (c) 2004-2005 ATI Technology, Inc.
View Drive Assignments........[1]
Define LD.....................[2]
Delete LD.....................[3]
Controller Configuration......[4]
[ Main Menu ]
Press 1..4 to Select Option [ESC] Exit
[ Keys Available ]
AMD ® FastBuild™ Utility
To enter the AMD ® FastBuild™ utility:
1. Boot up your computer.
2. Press + during POST to display the main menu of the utility.
