Chapter 1, 10 probeit – Asus MAXIMUS VI EXTREME User Manual
Page 64
1-48
Chapter 1: Product introduction
Chapter 1
1.2.10 ProbeIt
The ROG ProbeIt allows you to detect your system’s current voltage and OC settings. Use a
multimeter to measure the ProbeIt points even during overclocking.
See the illustration below to locate the respective ProbeIt points.
Using ProbeIt
You may connect the multitester to the motherboard as shown on the following figure.
The photos above are for reference only, the actual motherboard layout and measure
points location may differ by models.
