ASUS P5Q-E 3-17
• The following sub-items apprear only when you set the DRAM Timing
Control item to [Manual].
• The configuration options for some of the following items vary depending
on the DIMMs you install on the motherboard.
CAS# Latency [ 5 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks] [5 DRAM Clocks]
[6 DRAM Clocks] [7 DRAM Clocks]
DRAM RAS# to CAS# Delay [ 5 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks] – [17 DRAM
Clocks] [18 DRAM Clocks]
DRAM RAS# Precharge Time [ 5 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks] – [17 DRAM
Clocks] [18 DRAM Clocks]
DRAM RAS# Activate to Precharge Time [15 DRAM Clocks]
Configuration options: [3 DRAM Clocks] [4 DRAM Clocks] – [33 DRAM
Clocks] [34 DRAM Clocks]
RAS# to RAS# Delay [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
Row Refresh Cycle Time [Auto]
Configuration options: [Auto] [20 DRAM Clocks] [25 DRAM Clocks]
[30 DRAM Clocks] [35 DRAM Clocks] [42 DRAM Clocks]
Write Recovery Time [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
Read to Precharge Time [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
READ to WRITE Delay(S/D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
Write to Read Delay(S) [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
WRITE to READ Delay(D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
READ To READ Delay(S) [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
READ To READ Delay(D) [Auto]
Configuration options: [Auto] [1 DRAM Clocks] – [15 DRAM Clocks]
