4-20 Chapter 4: BIOS setup
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Advanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
NorthBridge Configuration
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
4.4.2 Chipset
The Chipset configuration menu allows you to change advanced chipset settings.
Select an item then press to display the sub-menu.
Configure CPU Bridge
features.
Uncore Configuration
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
CPU Bridge Chipset Configuration
CPU REVISION :B0
Current CSI Frequency :6.400GT
Current Memory Frequency :1066 Mhz
CSI Links Speed [Full-Speed]
CSI Frequency [Auto]
Memory Frequency [Auto]
Memory Mode [Independent]
Demand Scrubbing [Disabled]
Patrol Scrubbing [Disabled]
Throttling - Closed Loop [Disabled]
Throttling - Open Loop [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
To transition the CSI
links to full-speed
or leave them in
slow-mode.
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Uncore Configuration
IMC : ClarksField
Memory Remap Feature [Enabled]
PCI MMIO Allocation: 4GB To 3072MB
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
DRAM Margin Ranks [Disabled]
MRC Serial Debug Message Level [Disabled]
Spread Spectrum [Disabled]
Memory ECC Function [Enabled]
Double Rate Refresh [Auto]
Page Policy [Closed]
Adaptive Page [Disabled]
Data Scramble [Enabled]
Memory Thermal Throttling [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
ENABLE: Allow
remapping of
overlapped PCI memory
above the total
physical memory.
DISABLE: Do not allow
remapping of memory.
Memory Remap Feature [Enabled]
Setting this item to [Enabled] allows you to remapp the overlapped PCI memory
above the total physical memory. Configuration options: [Disabled] [Enabled]
DRAM Frequency [Auto]
You may allow the system to detect DDR3 memory frequency via SPD or designate
a specific frequency.
Configuration options: [Auto] [800 MHz] [1066 MHz] [1333 MHz]
Refer to the memory AVL on ASUS website at www.asus.com.
