P7F-E specifications summary
Model Name
P7F-E
Processor Support / System Bus
1 * Socket LGA1156
Quad Core Intel Xeon 3400 series Server
Processor
Quad Core Intel Core i7-800 series Desktop
Processor
Quad Core Intel Core i5-700 series Desktop
Processor
Dual Core 32nm CPU design Ready
Core Logic
Intel
®
3420 PCH
Form Factor
ATX, 12" * 9.6"
ASUS Features Fan Speed Control
V
Rack Ready (Rack and
Pedestal dual use)
V
ASWM 2.0
V
Memory
Total Slots
6/4 (RDIMM/UDIMM)
Capacity
Maximum up to 32GB (RDIMM)
Maximum up to 16GB (UDIMM )
Desktop Processor do not support RDIMM &
ECC UDIMM
Memory Type
DDR3 1066/1333 Unbuffered DIMM with ECC/
non ECC
DDR3 800*/1066/1333 Reg DIMM
Memory Size
1 GB, 2GB, 4GB, 8GB (RDIMM)
1 GB, 2GB, 4GB (UDIMM)"
Expansion Slots
(follow SSI
Loacation #)
Total PCI/PCI-X/PCI-E
Slots
6
Slot Loacation 1
1 * PCI 32bit/33 MHz
Slot Loacation 2
1 * PCI 32bit/33 MHz
Slot Loacation 3
1 * PCI-E x16 (Gen2 X8 Link)
Slot Loacation 4
1 * PCI-E x1 (x1 link)
Slot Loacation 5
1 * PCI 32bit/33 MHz
Slot Loacation 6
1 * PCI-E x16 (Gen2 x16 Link)
(Auto switch to x8 Link if slot 3 is occupied )
Slot Loacation 7
1* MIO Slot for Audio card
(PCI-E x1 is not supported)
Additional Slot 1
1* PIKE Slot for Stroage expansion
Refer to
2.3 Central Processing Unit for more information on CPU.
*Down from 1066 or 1333 MHz DIMM
