4-14 Chapter 4: BIOS setup
SATA Port1 [Auto]
Allows you to select the type of device connected to the system.
Configuration options: [Auto] [Not Installed]
SMART Monitoring [Enabled]
Allows you to set the Self-Monitoring, Analysis and Reporting Technology.
Configuration options: [Disabled] [Enabled]
SATA Port1–6 [XXXX]
Displays the status of auto-detection of SATA devices.
4.3.5 AHCI Configuration
This menu is the section for AHCI configuration. It appears only when you set the
item Configure SATA as from the sub-menu of SATA Configuration to [AHCI].
BIOS SETUP UTILITY
Main
AHCI Settings
SATA Port1 [Not Detected]
SATA Port2 [Not Detected]
SATA Port3 [Not Detected]
SATA Port4 [Not Detected]
SATA Port5 [Not Detected]
SATA Port6 [Not Detected]
Some SATA CD/DVD in
AHCI mode need to
wait ready longer.
BIOS SETUP UTILITY
Main
SATA Port1
Device :Not Detected
SATA Port1 [Auto]
SMART Monitoring [Enabled]
Select the type
of device connected
to the system.
