ASUS P7F-E 2-7
2.2.4 Layout contents
Slots/Soocket Page
1. CPU sockets 2-9
2. DDR3 sockets 2-15
3. MIO PCIE slot 2-19
4. PCI Express x 16 slot (x8 link) 2-19
5. PCI Express x 16 slot (x16 link) 2-19
6. PCI Express x 1 slot 2-19
7. PCI slot 2-19
8. PIKE slot 2-19
Jumpers Page
1. Clear RTC RAM (CLRTC1) 2-23
2. VGA controller setting (3-pin VGA_SW1)) 2-24
3. CPU Fan and Chassis Fan control setting
(3-pin CPUFAN_SEL1, CHAFAN_SEL1)
2-24
4. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 2-25
5. iBTN RAID setting (3-pin IBTN_SEL1) 2-25
6. RAID configuration utility selection (3-pin RAID_SEL1) 2-26
7. Force BIOS recovery setting (3-pin RECOVERY1) 2-26
Rear panel connectors Page
1. PS/2 mouse port (green) 2-27
2. RJ-45 port for iKVM 2-27
3. PS/2 keyboard port (purple) 2-27
4. USB 2.0 ports 1 and 2 2-27
5. Serial (COM1) port 2-27
6. Video Graphics Adapter port 2-27
7. LAN 1 (RJ-45) port 2-27
8. LAN 2 (RJ-45) port 2-27
