Page 39
ASUS P7F-E
2-21
2.5.12 Installing ASMB4 management board
Follow the steps below to install an optional ASMB4 management board on your
motherboard.
1. Locate the BMC_FW1 header on
the motherboard.
2. Orient and press the ASMB4
management card in place.
2.5.11 Installing i Button
Follow the steps below to install an optional i Button on your motherboard.
1. Locate the I Button slot on the
motherboard.
2. Snap the I Button in place.
You need to install I Button before using PIKE 1078 functions.
